eSafe 550 Series

eSafe Series 550 is a safety coupling that feature an easy to grip design with a fully automatic function. They are smaller, much more compact and generate higher flow than comparable designs. eSafe is a one hand operated safety coupling that vents before disconnection, eliminating the risk of hose whip.

• Vented safety function
• One hand operated
• Extremely high-flow capacity

DN 11 mm (7/16"). Flow capacity of 4050 l/min (143.0 CFM). Max working pressure 232 PSI (16 bar). Made of zinc-plated steel/brass. The eSafe version complies with ISO Standard 4414 and EN 983.
